Standard:DIN7504,DIN7504K,DIN7504P,DIN7504N
Size-Diameter:ST2.2-ST6.3
Size-Length:5mm-200mm
Material:Stainless Steel
Grade:SS304,SS316,SS410,A194-B8,INOX304,INOX316
Finish:Polish,Passivate
Company Certificate:ISO9001:2015
Product Certificate:Factory MTC and SGS
Package:Small box pack in carton then on wood pallet
Payment Term:TT OR LC AT SIGHT
Delivery Term:FOB,CNF,CIF,EXW
Delivery Time:Within 10-15days
SS410 material (it can’t drill or broken end if exceed the below scope)
Self drilling screw of #6(3.5) can drill the carbon steel plate(steel plate) with the thickness of 2.5mm.
Self drilling screw of #8(4.2) can drill the carbon steel plate(steel plate) with the thickness of 3 mm.
Self drilling screw of #10(4.8) can drill the carbon steel plate(steel plate) with the thickness of 4.5 mm.
Self drilling screw of #12(5.5） can drill the carbon steel plate(steel plate) with the thickness of 6 mm.
Self drilling screw of #14(6.3） can drill the carbon steel plate(steel plate) with the thickness of 8 mm.
SS304 and SS316 self drilling screw just can drill Aluminum Alloy sheet
It should be slowly when use the electrodrill.otherwise,the temperature will high cause aluminum scrap will dissolve easily which will stick to the thread of the self drilling screw and cause the aluminum scrap can't be discharged easily then will occur can't drill and broken end if use the electrodrill faster.
Self drilling screw of #6（3.5）can drill the Aluminum Alloy plate with the thickness of 2.5 mm.
Self drilling screw of #8（4.2）can drill the Aluminum Alloy plate with the thickness of 3 mm.
Self drilling screw of#10（4.8）can drill the Aluminum Alloy plate with the thickness of 4.5 mm.
Self drilling screw of#12（5.5）can drill the Aluminum Alloy plate with the thickness of 6 mm.
Self drilling screw of#14（6.3） can drill the Aluminum Alloy plate with the thickness of 8 mm.
APPLICATION
Construction Industry Chemical Plant Captive Power Plant
Railway Construction
Oil Platfrom
Shippbuilding Industry
